Search Results for: paris
standard
#FlatspotDeckOfTheDay: Loaded Cantellated Tesseract
The Cantellated Tesseract is the middle ground between the Truncated and Full Tesseract – Its a jack of all trades and a happy medium that wont hold you back.
standard
Orangatang – Moose Knuckles Bushings
JUICIER BOUNCE, TIGHTER PACKAGE.
Crafted for quick turning response and smooth edge-to-edge transitions, Orangatang Knuckles are the ultimate high-energy bushing upgrade for carving, pumping, dancing, and freestyle longboarding.
Orange = Soft
Purple = Medium
What’s in the box? Pack contains two insert barrel bushings, two gumdrop bushings, two large cup washers, and two small cup washers.
LONGBOARD BUSHING SPECS
Diameter: 0.95” (24.1 mm)
Height (gumdrop): 0.64” (16.3 mm)
Height (inset barrel) 0.59” (15 mm) barrel + 0.075” (1.91 mm) insert = 0.665” (16.9 mm) total
Formula: Randy Thane
Durometers: soft (orange, 87a), medium (purple, 90a)
RECOMMENDED WEIGHT RANGES
Soft: 65-190+ lbs / 29-86+ kg
Medium: 130-230+ lbs / 59-104+ kg
RESPONSIVE DESIGN – Two unique shapes for highly responsive and customizable turning. Sized for compatibility with most trucks. The inner diameter features precise tolerances for a snugger fit around the kingpin. The insert barrel features a small “step” to fill the gap between the kingpin and the hole of the hanger, reducing play in the assembly for a more precise response. The gumdrop is a smooth and subtle blend between a barrel and the more traditional cone shape, providing enhanced agility. The rounded edge allows for ultra-smooth turn initiation and improved interface with the washers.
HIGHLY TUNABLE – In the standard configuration, the insert barrel is placed on the bottom and the gumdrop on the top (like a traditional barrel/cone setup). You can also set up your trucks with double insert barrels (the height of the insert is half the thickness of a Paris bushing seat) or double gumdrops. Replace the included cup washers with flat washers for a less restrictive, highly linear turning rate.
RANDY THANE – Knuckles are poured in our extremely high-rebound Randy Thane formula, ideal for responsive, energetic turning.
KNUCKLES VS. NIPPLES – While both Knuckles and Nipples use the same Randy urethane formula, the two bushings offer distinct performance characteristics. Nipples are a great choice for riders seeking maximum rebound for pumping and carving, lively yet supportive turning, and reduced wheelbite. The wide (1” diameter) double-barrel design offers a highly defined center point with immediate resistance to turn that increases progressively with lean angle.
In contrast, Knuckles are well suited for riders seeking quicker edge-to-edge response and deeper carving capabilities. The narrower diameter (0.95”) and combination of shapes provide a blend between a stable base (barrel) and a more free-turning top (gumdrop). The result is quicker and easier turn initiation with less resistance and a greater ultimate lean angle. Additionally, Knuckles are compatible with most longboard trucks (including Paris, Bear, Randal, Carver, Gullwing, Tracker, Caliber, Atlas, Bolzen, Aera, Rogue, PNL, Ronin, etc).
standard
Orangatang – Nipples Bushings
Extra lively and energetic, these double barrel Nipples will get you all hot and heavy.
Sold as a set of four (4), including four thin and strong flat washers. Nipples are NOT recommended for every truck on the market, but they do work well with Paris, Tracker Fastracks and Randals (among others).
Orange = 85a = Soft
Purple = 87a = Medium
Yellow = 89a = Hard
What’s in the box? Purchase price includes 4 nipples and 4 washers.
Intention
Designed to provide a lively and energetic ride, Nipples will revitalize any setup for carving, pumping, dancing, freestyle and freeride.
Formula
Nipples are poured in our extremely high rebound Randy Urethane formula. We stumbled on this urethane a few years ago while testing ultra high rebound formulas for wheels, but we found this urethane to actually be too high rebound for a wheel urethane. Perfect for a bushing.
Specs & Features
Outer diameter: 1 inch
Height (top/roadside): 0.56 inch
Height (bottom/boardside): 0.66 inch
The bottom bushing carries most of the rider’s weight, so it is compressed more than the top bushing. The top bushing engages mostly when the rider leans in one direction to turn. To account for this difference in loading, we made the bottom bushing slightly taller than the top. Both top and bottom barrels are beveled on one edge for a better fit with large cupped washers (such as the stock parts on Paris and Tracker Racetrack trucks). However, we recommend flat washers in general (see below).
The first round of Nipples are packaged in sets of four bushings (two bottom barrels and two top barrels) and include four flat washers.
Hardness
The first release of Nipples will feature three hardness ratings: soft, medium, and hard. These are roughly equivalent to ratings of 85a, 87a, and 89a on the Shore A durometer scale. The reason we’ve chosen to use a relative hardness scale for our bushings is that Nipples feel and respond differently than many equivalently rated bushings, due to their dimensions. The Nipples feature a slightly larger-than-average diameter that is intended to provide more leverage against the hanger and more meaty volume to compress in every turn. Combined with a double barrel configuration, this allows for a predictable initiation and very consistent resistance throughout the hanger’s travel, even in softer durometers.
Recommended weight ranges for lower speed (under 20 mph) riding are below. For faster riding, we recommend going harder.
Soft (orange): 80-180 lbs / 35-85 kg
Medium (purple): 160-230 lbs / 70-105 kg
Hard (yellow): 200-270 lbs / 90-125 kg
Washers
We tested many washer configurations while developing our bushings and ultimately found that flat washers on both sides provided the response we were looking for. We found, however, that most commercial flat washers we tested were lacking in one performance area or another. Some were made of soft materials that bent over time, and most did not have the kind of consistency in thickness from one washer to the next that we wanted (thicker washers not only modify the angle at which the hanger sits but also tend to result in excess compression and a deadened feeling). So we decided to develop our own flat washers.
Our washers feature a 1-inch outer diameter and are 0.055 inch thick. They are made of strong, medium-carbon steel that resists bending. The manufacturing tolerances are very tight, so dimensions are consistent between parts. The wide diameter and low thickness help support the entire bushing without degrading their performance or interfering with the truck’s geometry.
While the Nipples are packaged with our own flat washers, there are many other washer setups that can change the riding experience. For instance, large cupped washers can be used for a slightly more restrictive feel, while a flipped small cup washer on the top bushing will provide a slightly “looser” turning response.
Compatibility
Nipple bushings fit Paris, Tracker Fastrack, Gullwing Charger II, and old (pre-2010) Bear trucks. They are not compatible with new Bears, Gullwing Chargers, or Indys. Nipples work with Randal trucks, but they do not sit completely contained in the bushing seat. Since the Randal bushing seat is so low, however, it does not interfere with the performance of the bushings. They fit Caliber trucks, but the lean becomes very restricted past a certain point.
Many of our ambassadors have also run Nipples in various precision trucks (e.g. Aera and Omen) with good results.
This compatibility list is based on the trucks we use most. Nipples will fit in any truck that can accommodate a 1-inch diameter bushing with a height of 0.66 (bottom) and 0.56 (top) inch.
Future Directions
We look forward to exploring many variations in bushing design in the future including shapes, sizes, and formulas.
standard
Flatspot Longboards Weekly 12.16.15: Nate BlackBurn, G-form Pads, #FLATSPOTSHREDMAS and More!
Its that time of the week again! Get the low down on highlights, specials and events all tailored for your sifting pleasure.
standard
Pro Tribute Set Up: Nate Blackburn
Nate Blackburn may not be on every single podium, but he is a professional in every sense of the word! And today we are gonna pick apart his set up.
standard
standard
Flatspot Longboards: Weekly Wrap Up Nov 17th 2015
Check out the highlights from this week in our Weekly Wrap Up! Punk shows, deals on fullfaces, learn to stop sessions. Its all here!
standard
Flatspot Team: Troy Grenier
RIDER BIO
Name: Troy Grenier
Born: 1992
Sponsors: Landyachtz, Hawgs Wheels, Paris Trucks, S1 helmets, Push Culture, Timeship Racing, Flatspot longboardshop, Bambuddha sunglasses, Skate slate, venom bushings, paradox grip (Light Speed Division), cariboo brewing
Favorite Set Up(s):
Born: 1992
Sponsors: Landyachtz, Hawgs Wheels, Paris Trucks, S1 helmets, Push Culture, Timeship Racing, Flatspot longboardshop, Bambuddha sunglasses, Skate slate, venom bushings, paradox grip (Light Speed Division), cariboo brewing
Favorite Set Up(s):
- Landyachtz loco 33, 155mm polar bears, street hawgs 57mm 99a
- Landyachtz Ramathorn, Bear Kodiaks, Hawgs Tracers, Space ball bearings, 93a venom barrel board side 90a venom barrel roadside.
- Landyachtz Triple Beam, Bear Koodiaks, Biggie hawgs and 93a venom barrel board side 90a venom barrel roadside.
Instagram: @Troy_Yardwaste
Troy Grenier lives and breathes Coast Longboarding. He has been on more Cribb Bomb trips than most and is a master of the open road. As for his skating, it speaks for itself. Parks, hills ditches or your driveway, he will slay it. If troy is hitting up an event, expect to see him on the podium. Few are more determined to dominate.
standard
Troy Grenier Raw Run – Downhill Manual – Flatspot Longboards
Flatspot team rider Troy Yardwaste lays down a massive and stupidly fast manual long enough to earn its own raw run!
standard
Omen – Sugar – Deck
The Omen Sugar boils down some of the most basic aspects of what makes a freeride board good and blends them into a carefully balanced meal of radness. Start with a solid rocker, add some flares for clearance, flushmounts to not overpower the flavour of your trucks, and finish off with a kicktail. Gangster graphic as garnish adds a nice visual touch. Voila, a culinary masterpiece! Cutthroat kitchen would get dominated by Omen if they were to somehow come together.
To really make this deck a full course here is the soup of the day and a salad to go with it.
Zealous – Ceramic Bearings
$39.99CADZealous downhill Ceramic precision Spaced longboard Bearings
Ceramic Balls
-Ceramic balls are lighter, stiffer, smoother and naturally corrosion resistant. This means we can use a lower viscosity lubricant which makes them fast right out of the tube.
– Precision 8mm axle holes
– .4045″ built in spacers
– .5mm built in speedrings
– Strengthened Nylon Ball Retainers
– White rubber seals to keep dirt and debris on the outside of the bearing.
– Lubed with Custom Nanoceramic Grease
-The unique feature of our lubricant is how the nanoceramic compound fills in deformations or asperities in the bearing. These deformations cause friction and heat around them which hardens the nano-ceramic compound to that specific area. This micro coating is 5 times the hardness of the host alloy and has a molecular bond with the host metal, filling in all the asperities and eliminating friction over time.
-The coefficient of friction is the lowest in the field of Tribology at 0.003% creating a near frictionless surface. Mainly because the nanoceramic compound eliminates all asperities.
-Corrosion on the inside of the bearing is nearly eliminated.Sold in sets of 8 bearings.
